Delock LTE UMTS GSM Antenna N jack 7 - 10 dBi directional wall and pole mounting outdoor

Reference 12435

Condition: New

More info

- LTE Band: 1/2/3/4/5/6/7/8/9/10/12/13/14/15/16/17/18/19/20/25 • 698 ~ 960 MHz + 1710 - 2700 Mhz • 7 - 10 dBi • vertical beam width: 55° • horizontal beam width: 70° • GSM/UMTS - Polarisation vertical - 50 Ohm - VSWR: 1,8:1 - N Buchse - Abmessungen (LxBXH): 210 x 180 x 45 mm - Kabellänge: ca. 0,30 m - Kabeltyp: RG58 - op. Temp. -10°C ~ 70°C - ABS UV resitant - IP 55 - inkl. Mast- und Wandmontagesatz • Gewicht: 500g

System requirements:
• Cable with N plug

Specification:
• Connector: 1 x N jack
• Frequency range:
698 - 960 MHz
1710 - 2700 MHz
• ZigBee, Bluetooth, WLAN 2.4 GHz, DECT, Z-Wave, LoRa 868 MHz / 915 MHz
• Antenna gain: 7 - 10 dBi
• Impedance: 50 Ohm
• Polarisation: vertical
• HBW horizontal beamwidth: 70°
• VBW vertical beamwidth: 55°
• VSWR: 1.8
• Transmission power: max. 100 W
• Housing material: ABS
• Colour: white
• Operating temperature: -40 °C ~ 70 °C
• Dimensions (LxWxH): ca. 210 x 180 x 45 mm

Package content:
• LTE antenna
• Mounting material

Data sheet:
http://www.delock.de/produkt/12435/pdf.html?sprache=en
