Delock LTE Antenna N Plug 3 dBi omnidirectional fix roof mount outdoor

DELOCK

12604

New

This LTE antenna by Delock allows the usage of different LTE bands inside and outside. It is completely compatible to GSM, UMTS, Bluetooth, WLAN 2.4 GHz, ZigBee, DECT, Z-Wave and LoRa 868 MHz / 915 MHz.
System requirements:
• Device with a free N jack
Specification:
• Connector: 1 x N plug
• GSM, UMTS, Bluetooth, WLAN 2.4 GHz, ZigBee, DECT, Z-Wave, LoRa 868 / 915 MHz
• Frequency range:
  698 - 960 MHz
  1710 - 2170 MHz
  2500 - 2700 MHz
• Antenna gain: 3 dBi
• Impedance: 50 Ohm
• VSWR: 2.0
• Polarisation: vertical
• Mounting type: screw mounting
• Mounting hole diameter: 13.5 mm
• Operating temperature: -40 °C ~ 70 °C
• Housing material: ABS
• Protection class: IP67
• Colour: black
• Dimensions (LxWxH): ca. 64 x 22 x 22 mm
Package content:
• LTE antenna
Data sheet:
http://www.delock.de/produkt/12604/pdf.html?sprache=en
