Icy Box Dockingstation Notebook IcyBox USB-C -> 3x Videoausgabe 60H

ICY BOX

IB-DK2244AC

New

Always prepared This high performance DockingStation can be used with both current Windows® and macOS® operating systems. Thus, the IB-DK2244AC is the perfect companion for eager travellers, business and multimedia enthusiasts who want to be prepared for all environments.One connection Notebooks and other mobile devices are getting thinner and smaller. This is usually at the expense of connectivity options – even the widespread RJ45 LAN port or extra USB inputs are often drastically reduced as are connections for video transmission, that many display devices require. The IB-DK2244AC offers a wide variety of interfaces and makes this an issue of the past.High resolution The IB-DK2244AC is equipped with five display video outputs. With triple Ultra HD displays simultaneously, the DockingStation allows you to split up the content to three display devices when the system supports the function, to mirror your primary screen or extend the computers desktop allowing visibility of more applications at the same time. It supports a resolution of up to 4096x2160@60 Hz for two monitors or one single 5K@60Hz display with two cables connected via DisplayPort™ and fulfils your high resolution desires.

Connectivity technologyWired
Host interfaceUSB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity5
HDMI ports quantity3
Microphone inY
Headphone outputs1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity1
USB Power DeliveryY
USB Power Delivery revision2.0
USB Power Delivery up to60 W
DisplayPorts quantity2
DisplayPort version1.2
Headphone connectivity3.5 mm
DC-in jackY
USB Type-C DisplayPort Alternate ModeY
Ethernet LANY
Ethernet LAN (RJ-45) ports1
Ethernet LAN data rates10,100,1000 Mbit/s
Product colourBlack
Card reader integratedN
Data transfer rate5 Gbit/s
HD type5K Ultra HD
Maximum digital resolution5120 x 2880 pixels
Number of displays supported3
Maximum refresh rate60 Hz
Cable lock slotY
Cable lock slot typeKensington
Plug and PlayY
Charging functionY
UASP supportY
Housing materialAcrylonitrile butadiene styrene (ABS), Polycarbonate (PC)
Country of originChina
Power source typeDC
Power supply135 W
Output voltage50 V
Output current6.75 A
Windows operating systems supportedY
Mac operating systems supportedY
Width250 mm
Depth80 mm
Height35 mm
Weight392 g
Quantity per pack1 pc(s)
Package width290 mm
Package depth95 mm
Package height155 mm
Package weight1.56 kg
Cables includedUSB Type-C to USB Type-C
AC adapter includedY
ManualY
Products per master (outer) case9 pc(s)
Master (outer) case width305 mm
Master (outer) case length495 mm
Master (outer) case height310 mm
Master (outer) case gross weight14.7 kg
Harmonized System (HS) code84733020
Cable length1 m

Docking Station
