Level One LevelOne WLAN Access Point & Extender outdoor 5GHz PoE
Previous Next

Level One LevelOne WLAN Access Point & Extender outdoor 5GHz PoE

LEVEL ONE

WAB-8010

New

WAB-8010 AC900 5GHz Outdoor PoE Wireless Access Point

Model Number
WAB-8010
SKU
54710103101
  • Provides wireless speeds of up to 867Mbps
  • Compatible with IEEE 802.11ac Wave 2 wireless standards
  • MU-MIMO technology greatly enhances WLAN performance for all clients
  • Supports DIP switch configuration for AP mode and Repeater mode features.
  • Transmission distance of up to 5km for 5GHz
  • Dual power support: 12V DC/PoE (IEEE 802.3af)
  • Provides up to 4 SSIDs to separate network traffic and enhance security
  • Weatherproof IP65-rated housing
The LevelOne WAB-8010 outdoor single-band 802.11ac wireless access point, capable of 867 Mbps wireless internet speeds and distance of up to 5km. Supply 802.11ac Wave 2 MU-MIMO (Multi-User Multiple-Input Multiple-Output), allows multiple devices to get high- bandwidth Wi-Fi signal at the same time, distributing data more efficiently.

The device runs on 5 GHz frequency, also offers PoE, removing the need for an external power supply, which makes it easy to install. Advanced weatherproof design, rated to IP65 means the WAB-8010 is designed for outdoor deployments, and can withstand rain, humidity, dust and snow. A fast, versatile and secure access point for a wide variety of outdoor network requirements.
Other
Approval and complianceCE, RoHS
Operating humidity10% RH ~ 90% RH
Operating temperature-30°C ~ 45°C
Storage humidity5% RH ~ 95% RH
Storage temperature-40°C ~ 75°C
System specifications
AntennaBuild in 14dBi MIMO Panel Antenna
EIRP (dBm)<20 dBm
EncryptionWPA2-PSK (AES), Auto Encryption (WPA/WPA2-PSK)
Frequency band4.920~5.920 GHz
IndicatorsSYS、WAN、LAN、WI-FI signal strength(25%, 50%, 75%, 100%)
RAM size128 MByte (DDR2)
Flash memory size16 MByte
MountPole mount
Operating modesAP Mode, Repeater Mode
Power supplyPoE (IEEE 802.3af), DC12V/1.5A(Power supply is not included)
Standards802.11ac/a/n, MU-MIMO technology
Wireless channelsCh.36~165 by Country
Port Configuration2 x RJ45
Features
FeaturesMulti-SSID: 4 SSIDs (5GHz x 4 SSIDs)
Physical Specifications
Product weight (kg)0.44
Default
ColorWhite
EAN4015867226889
Model NumberWAB-8010
Package contentsWAB-8010,
Pole Mounting Hose Clamp (40-64mm),
RJ45 Network Cable,
Quick Installation Guide,
EU Declaration of Conformity
Port Configuration
Gigabit RJ451 LAN Ports (10/100/1000Base-T)
802.3af/at PoE1 WAN Port ( 10/100/1000Base-T )
Performance
Receiver sensitivity802.11ac HT20
• MCS0：-89dBm
• MCS7：-67 dBm
• MCS9：-62dBm

802.11ac HT40
• MCS0：-86dBm
• MCS7：-64dBm
• MCS9：-59dBm

802.11ac HT80
• MCS0：-82dBm
• MCS7：-60dBm
• MCS9：-55dBm
Filter
Frequency band5GHz
Wireless AP TypeOutdoor
PoE SupportedYes
