VALUE Fibre Optic Jumper Cable, 50/125µm, LSOH, LC/LC, OM4, Flex boots, 2 m

VALUE

21.99.8792

Jauns

OM4 fiber for existing 1 and 10 Gbit/s applications as well as future 40 and 100 Gbit/s systems. Allows extended reach upwards of 550 meters at 10 Gbit/s for ultra long building backbones and medium length campus backbones. With an laser bandwidth of 4700 MHz-km (more than double the IEEE requirement for 10 Gbit/s 300 meter support), the OM4 fiber is also especially well suited for shorter reach in data centers and high performance computing applications.

  • VALUE OM4 Fibre Optic Jumper cable with fiber type 50/125 µm
  • Designed for the use in high density environments, tight constraint areas
  • These fiber optic patch cords with flex boots are ideal for cable management situations where additional fiber bend protection can be very helpful
  • The boot can be pre-bend into any direction or angle (this position allows optimal network performance)
  • It can be reshaped at any time or straightened for disconnection of the cable
  • Flexible in any direction
  • Helps/prevent fiber congestion
  • Controls force and bend radius
  • Color: violet



ManufacturerVALUE
Product groupFibre optic cable
Product typeFibre Optic Jumper Cables OM4
Colourviolet
Length2 m
Quantity of fibre2
Conductor compositionCompact conductor
Cable typeDuplex Cable
External cable
Fibre section50/125µm OM4
Connection portsLC / LC
Side 1 Connector TypeLC
Side 2 Connector TypeLC
Kevlar strain relief
External cable diameter2 mm
Mantle of external cableLZOH
Cable LSOH
Technical particularityUPC Polish
Current catalog editionC20-01.51

9/125 62.5/125 50/124 MTP
