Level One LevelOne WLAN Access AX1800 Wireless PoE DualBand WiFi6

LEVEL ONE

WAP-8131

Jauns

The LevelOne WAP-8131 is a standalone, AX1800 dual-band Wi-Fi 6 PoE wireless access point that features dual Gigabit Ethernet ports and advanced 802.11ax Wave 2 MU-MIMO (Multi-User Multiple-Input Multiple-Output), allows multiple devices to get high-bandwidth Wi-Fi signal at the same time, distributing data more efficiently. capable of a combined speed of up to 1775 Mbps. The WAP-8131 provides 2.4 and 5 GHz frequencies and can be used as a high-quality stand-alone access point in a corporate environment or for demanding installations. It also offers support for the new WPA3 encryption. Of course, the WAP-8131 is also equipped with PoE, which eliminates the need for an external power supply, simplifying installation. A fast, versatile and secure access point for a variety of network requirements, especially when high speeds are important for many users.

2.4 GHzY
5 GHzY
6 GHzN
Maximum data transfer rate1800 Mbit/s
Maximum data transfer rate (2.4 GHz)574 Mbit/s
Maximum data transfer rate (5 GHz)1201 Mbit/s
Frequency band2.412 - 2.484, 5.18G -5.825
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Channels quantity165 channels
MIMOY
MIMO typeMulti User MIMO
Spread spectrum methodOFDMA
Operating modesGateway, Repeater, AP
Security algorithmsAES, WPA, WPA2, WPA3
Service Set Identifier (SSID) featuresMultiple SSIDs
Number of SSID supported8
Web-based managementY
Ethernet LAN (RJ-45) ports2
DC-in jackY
Power over Ethernet (PoE)Y
Power consumption (max)14 W
PlacementCeiling, Wall
Product colourWhite
LED indicatorsStatus
Country of originChina
Antenna typeInternal
Antennas quantity4
Antenna gain level (max)4 dBi
ChipsetQualcomm IPQ6000
Flash memory128 MB
Internal memory512 MB
Master (outer) cases per pallet (air)10 pc(s)
Pallet net height164.4 cm
Pallet net length80 cm
Pallet net width120 cm
Width186 mm
Depth186 mm
Height42.5 mm
Weight418.5 g
Package width243 mm
Package depth235 mm
Package height76 mm
Package weight750 g
Cables includedLAN (RJ-45)
Quick start guideY
Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)0 - 55 °C
Storage temperature (T-T)0 - 70 °C
Storage relative humidity (H-H)5 - 90%
Sustainability complianceY
Sustainability certificatesCE, RoHS
Master (outer) case width410 mm
Master (outer) case length520 mm
Master (outer) case height500 mm
Master (outer) case gross weight16 kg
Products per master (outer) case20 pc(s)
