Level One LevelOne WLAN Access Point outdoor PoE DualBand AX3000 WiFi6

LEVEL ONE

WAB-8021

Jauns

The LevelOne WAB-8021 is a standalone, AX3000 Omni-directional outdoor dual-band Wi-Fi 6 PoE wireless access point that features Gigabit Ethernet ports and advanced 802.11ax Wave 2 MU-MIMO (Multi-User Multiple-Input Multiple-Output), allows multiple devices to get high-bandwidth Wi-Fi signal at the same time, distributing data more efficiently. capable of a combined speed of up to 2976 Mbps(574Mbps in 2.4GHz/2401Mbps in 5GHz) and Omni-directional outdoor transmission distance of up to 100m.

The device runs on 2.4 and 5 GHz frequency, It also offers support for the new WPA3 encryption. Of course, the WAB-8021 is also equipped with PoE, removing the need for an external power supply, which makes it easy to install. Advanced weatherproof design, rated to IP67 means the WAB-8021 is designed for outdoor deployments, and can withstand rain, humidity, dust and snow. A fast, versatile and secure access point for a wide variety of outdoor network requirements.


2.4 GHz
5 GHz
6 GHz
Maximum data transfer rate3000 Mbit/s
Maximum data transfer rate (2.4 GHz)574 Mbit/s
Maximum data transfer rate (5 GHz)2401 Mbit/s
Ethernet LAN data rates10,100,1000 Mbit/s
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Cabling technology10/100/1000Base-T(X)
Channels quantity165 channels
MIMO
MIMO typeMulti User MIMO
Spread spectrum methodOFDMA
Maximum outdoor range100 m
Receiver sensitivity2.4 GHz Radio : l 802.11b / 1Mbps / RX Sensitivity : -90 (dBm) l 802.11b / 11Mbps / RX Sensitivity : -85 (dBm) l 802.11g / 6Mbps / RX Sensitivity : -90 (dBm) l 802.11g / 54Mbps / RX Sensitivity : -72 (dBm) l 802.11n HT20 / MCS0 / RX Sensitivity : -87 (dBm) l 802.11n HT20 / MCS7 / RX Sensitivity : -70 (dBm) l 802.11n HT40 / MCS0 / RX Sensitivity : -85 (dBm) l 802.11n HT40 / MCS7 / RX Sensitivity : -68 (dBm) l 802.11ax HE20 / MCS0 / RX Sensitivity : -83 (dBm) l 802.11ax HE20 / MCS11 / RX Sensitivity : -60 (dBm) l 802.11ax HE40 / MCS0 / RX Sensitivity : -83 (dBm) l 802.11ax HE40 / MCS11 / RX Sensitivity : -56 (dBm) 5 GHz Radio : l 802.11a HT20 / 6Mbps/ RX Sensitivity : -92 (dBm) l 802.11a HT20 / 54Mbps/ RX Sensitivity : -72 (dBm) l 802.11n HT20 / MCS0 / RX Sensitivity : -90 (dBm) l 802.11n HT20 / MCS7 / RX Sensitivity : -70 (dBm) l 802.11n HT40 / MCS0 / RX Sensitivity : -88 (dBm) l 802.11n HT40 / MCS7 / RX Sensitivity : -68 (dBm) l 802.11ac VHT20 / MCS0 / RX Sensitivity : -88 (dBm) l 802.11ac VHT20 / MCS8 / RX S
Security algorithmsWPA2, WPA3
Number of SSID supported8
Ethernet LAN (RJ-45) ports1
WAN connectionWi-Fi
Power over Ethernet (PoE)
Power consumption (typical)16 W
PlacementPole
Product colourWhite
International Protection (IP) codeIP67
LED indicatorsPower, Status, System
Country of originChina
Antenna typeInternal
Antenna direction typeOmni-directional
Flash memory128 MB
Internal memory512 MB
Width230 mm
Depth107 mm
Height38 mm
Weight1.3 kg
Package width380 mm
Package depth230 mm
Package height107 mm
Package weight1.73 kg
Package typeBox
Number of products included1 pc(s)
Mounting kit
Quick start guide
Operating relative humidity (H-H)10 - 90%
Operating temperature (T-T)-20 - 50 °C
Storage temperature (T-T)-20 - 80 °C
Storage relative humidity (H-H)5 - 95%
Sustainability certificatesCE, RoHS
Wireless standardIEEE 802.11a/b/g/n/ac/ax
