Level One LevelOne Kabel AOC-0503 100GBPS QSFP28 Active Optical 3m

LEVEL ONE

AOC-0503

Jauns

The LevelOne Quad Small Form-factor Pluggable 28 (QSFP28) active optic cable is further increase performance for applications that are I/O-intensive for 100G Ethernet. This connecting system offer 4 channels and maximun 100Gbps which are based on the proprietary technique Chip on board (COB), This module provides high performance and excellent efficiency in optical communication, offers system developers and planners a high degree of flexibility.

SFP transceiver typeFiber optic
Maximum data transfer rate103100 Mbit/s
Interface typeQSFP28
Fiber optic connectorQSFP28
SFP transceiver standardSR4
Wavelength850 nm
Networking standardsIEEE 802.3bm
Product colourAqua colour, Silver
Plug and PlayY
Country of originTaiwan
Brand compatibilityUniversal
Maximum operating temperature70 °C
Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-40 - 85 °C
Operating relative humidity (H-H)0 - 85%
Storage relative humidity (H-H)0 - 90%
Width18.4 mm
Depth8.5 mm
Height3000 mm
Weight117 g
Number of products included1 pc(s)
User guideY
Package width210 mm
Package depth0.5 mm
Package height260 mm
Package weight142 g
Package typeBag
Pallet net height164.4 cm
Pallet net length80 cm
Pallet net width120 cm
Harmonized System (HS) code85369010
Cable length3 m
