| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| PTZ control | Y |
| Day/night mode | Y |
| Infrared (IR) cut-off filter | Y |
| Certification | CE/FCC |
| Mounting type | Ceiling |
| Product colour | Black, White |
| Form factor | Dome |
| LED indicators | Power |
| International Protection (IP) code | IP66 |
| Country of origin | China |
| Minimum illumination | 0.01 lx |
| Field of view (FOV) angle | 58.3° |
| Tilt angle range | -15 - 90° |
| Tilt preset speed | 80 °/sec |
| Pan range | 0 - 360° |
| Pan speed | 80 °/sec |
| Auto flip | Y |
| Camera shutter speed | 1 - 1/10000 s |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Progressive scan | Y |
| Number of lenses | 1 |
| Optical zoom | 20x |
| Maximum aperture number | 3.5 |
| Minimum aperture number | 1.6 |
| Focal length range | 4.7 - 94 mm |
| Night vision | Y |
| Night vision distance | 100 m |
| LED type | IR |
| Maximum resolution | 1920 x 1080 pixels |
| Total megapixels | 2 MP |
| Video formats supported | AVI |
| Video compression formats | H.264, M-JPEG |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Frame rate | 60 fps |
| Full HD | Y |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Privacy masking | Y |
| Digital Wide Dynamic Range (DWDR) | Y |
| Audio input channels | 1 |
| Audio output channels | 1 channels |
| Audio codecs | G.711/G.722/G.726/MP2L2 |
| Ethernet LAN | Y |
| Wi-Fi | N |
| Bluetooth | N |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.3at |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
| Cabling technology | 10/100Base-T(X) |
| Number of users | 16 user(s) |
| Quality of Service (QoS) support | Y |
| Built-in HDD | N |
| Card reader integrated | Y |
| Compatible memory cards | SD, SDHC, SDXC |
| Maximum memory card size | 128 GB |
| Ethernet LAN (RJ-45) ports | 1 |
| DC-in jack | Y |
| Interface | RJ-45 |
| Password protection | Y |
| IP address filtering | Y |
| Anti-flicker | Y |
| Heartbeat | Y |
| Mirror | Y |
| Digital watermark | Y |
| Web browser | Y |
| Reset button | Y |
| Power source type | PoE |
| Power consumption (Power over Ethernet (PoE)) | 20 W |
| DC output voltage | 12 |
| Power over Ethernet (PoE) | Y |
| Operating temperature (T-T) | -30 - 65 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8 |
| Width | 295 mm |
| Depth | 164.5 mm |
| Height | 164.5 mm |
| Weight | 2 kg |
| Package width | 218 mm |
| Package depth | 384 mm |
| Package height | 218 mm |
| Package weight | 2.2 kg |
| Package type | Box |
| Number of cameras | 1 |
| Quick installation guide | Y |
| Resource CD | Y |
| Data transfer rate | 16 Mbit/s |
| Browser supported | Internet Explorer 9+ |
| Harmonized System (HS) code | 85258900 |
| Master (outer) case width | 460 mm |
| Master (outer) case length | 405 mm |
| Master (outer) case height | 460 mm |
| Master (outer) case gross weight | 9.5 kg |
| Products per master (outer) case | 4 pc(s) |
