| Type | IP security camera | | Placement supported | Outdoor | | Connectivity technology | Wired | | PTZ control | Y | | Auto pan mode | Y | | Auto patrol mode | Y | | Preset points | Y | | Wide Dynamic Range (WDR) | Y | | Day/night mode | Y | | Infrared (IR) cut-off filter | Y | | Certification | CE, FCC, ONVIF, IP67, IK09, NEMA 4X | | Mounting type | Wall | | Product colour | Black, White | | Form factor | Dome | | LED indicators | Power | | Protection features | Vandal proof | | International Protection (IP) code | IP67 | | IK code | IK09 | | Weatherproof | Y | | Country of origin | Taiwan | | Minimum illumination | 0.05 lx | | Tilt angle range | -20 - 200° | | Pan range | 0 - 360° | | White balance | Auto | | Camera shutter type | Electronic | | Camera shutter speed | 1/5 - 1/10000 s | | Sensor type | CMOS | | Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") | | Progressive scan | Y | | Number of lenses | 1 | | Zoom capability | Y | | Optical zoom | 30x | | Digital zoom | 16x | | Auto focus | Y | | Focal length range | 4.3 - 129 mm | | Focus adjustment | 1.6 - 5.0 | | Night vision | Y | | Maximum resolution | 1920 x 1080 pixels | | Total megapixels | 2 MP | | Video formats supported | RAW | | Video compression formats | H.264, M-JPEG | | Supported graphics resolutions | 320 x 240, 640 x 480 (VGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080) | | Supported video modes | 240p, 480p, 720p, 1080p | | Frame rate | 30 fps | | Video streaming | Y | | Noise reduction | Y | | Automatic gain control | Y | | Full HD | Y | | Image quality adjustment | Brightness, Contrast, Saturation, Sharpness | | Flip & mirror | Y | | Portrait mode | Y | | Privacy masking | Y | | Time stamp overlay | Y | | Text caption overlay | Y | | Back Light Compensation (BLC) | Y | | Audio system | 2-way | | Built-in microphone | N | | Voice codecs | G.711 | | Ethernet LAN | Y | | Wi-Fi | N | | Bluetooth | N | | Ethernet interface type | Fast Ethernet | | Networking standards | IEEE 802.3, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u | | Supported network protocols | TCP, UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, IPv6, DNS, DDNS, NTP, ICMP, ARP, IGMP, SMTP, FTP, UPnP, SNMP, Bonjour | | Built-in HDD | N | | Card reader integrated | Y | | Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC | | Maximum memory card size | 64 GB | | Ethernet LAN (RJ-45) ports | 1 | | Microphone in | Y | | Headphone outputs | 1 | | Terminal block port | Y | | Interface | RJ-45 | | Password protection type | User | | IP address filtering | Y | | HTTPS encryption | Y | | Motion sensor | Y | | Reset button | Y | | Power source type | PoE | | Power consumption (typical) | 25.44 W | | Power consumption (max) | 31.5 W | | Power consumption (Power over Ethernet (PoE)) | 31.5 W | | Power over Ethernet (PoE) | Y | | Operating temperature (T-T) | -40 - 50 °C | | Operating relative humidity (H-H) | 10 - 85% | | Windows operating systems supported | Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64 | | Width | 191 mm | | Depth | 191 mm | | Height | 282 mm | | Weight | 2.75 kg | | Package width | 269 mm | | Package depth | 246 mm | | Package height | 422 mm | | Package weight | 2 kg | | Package type | Box | | Number of cameras | 1 | | Cables included | AC | | Screws included | Y | | AC adapter included | Y | | Quick installation guide | Y | | Resource CD | Y | | Iris | Y | | Sustainability certificates | RoHS | | Harmonized System (HS) code | 85258900 | | Master (outer) case width | 565 mm | | Master (outer) case length | 525 mm | | Master (outer) case height | 445 mm | | Master (outer) case gross weight | 20.7 kg | | Products per master (outer) case | 4 pc(s) | | Number of video streams | 4 |
|
