Level One LevelOne IPCam FCS-1158 Fix In 5MP H.265 7W PoE

LEVEL ONE

FCS-1158

Jauns

The LevelOne FCS-1158 is a fixed-position outdoor camera offering an ultra-reliable, cost-effective solution for indoor IP surveillance networks. Offering clear, sharp imagery with 5-Megapixel resolution and the versatility of 802.3af standard PoE to transfer power and data via a single Cat.5 cable, the LevelOne FCS-1158 should be an essential part of any security deployment that requires smart, reliable indoor cameras.

TypeIP security camera
Placement supportedIndoor
Connectivity technologyWired
Wide Dynamic Range (WDR)Y
Day/night modeY
CertificationCF/FCC
Mounting typeCeiling/wall
Product colourBlack, Grey
Form factorBullet
LED indicatorsPower
Country of originTaiwan
Minimum illumination0.05 lx
Field of view (FOV) angle89.1°
White balanceAuto
Camera shutter typeElectronic
Camera shutter speed1/5 ~ 1/16000 s
Adjustment shutter speedAuto/Manual
Sensor typeCMOS
Optical sensor size25.4 / 1.8 mm (1 / 1.8")
Progressive scanY
Number of lenses1
Maximum aperture number2.8
Minimum aperture number1.5
Focal length range3.6 - 10 mm
Night visionY
Maximum resolution2592 x 1944 pixels
Total megapixels5 MP
Video formats supportedRAW
Video compression formatsH.264, H.265, M-JPEG
Supported graphics resolutions320 x 240, 640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 2592 x 1944
Supported video modes240p, 480p, 720p, 1080p
Frame rate30 fps
Noise reductionY
3D NR (Noise Reduction)Y
Gain control typeAuto
Full HDY
Image quality adjustmentBrightness, Contrast, Sharpness
Audio input channels1
Audio output channels1 channels
Audio formats supportedG.711
Built-in microphoneY
Ethernet LANY
Wi-FiN
BluetoothN
Ethernet interface typeGigabit Ethernet
Networking standardsIEEE 802.3af
Supported network protocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP,IGMP, 802.1X, IPv6, Bonjour
Cabling technology10/100/1000Base-T(X)
Quality of Service (QoS) supportY
Built-in HDDN
Card reader integratedY
Compatible memory cardsMicroSDHC, MicroSDXC
Maximum memory card size64 GB
Ethernet LAN (RJ-45) ports1
RS-422 ports1
RS-485 ports1
Composite video out1
BNC output ports1
Terminal block portY
InterfaceRJ-45
Video motion detectionY
Web browserY
Reset buttonY
Power source typeDC, PoE
Power consumption (typical)7 W
Power consumption (Power over Ethernet (PoE))12.95 W
DC output voltage12
DC output current0.6 A
Power over Ethernet (PoE)Y
Operating temperature (T-T)10 - 50 °C
Operating relative humidity (H-H)10 - 90%
Windows operating systems supportedWindows 10, Windows 7, Windows 8
Width58 mm
Depth62 mm
Height125 mm
Weight360 g
Package width200 mm
Package depth90 mm
Package height200 mm
Package weight735 g
Package typeBox
Number of cameras1
Resource CDY
IrisY
Harmonized System (HS) code85258900
Master (outer) case width405 mm
Master (outer) case length367 mm
Master (outer) case height405 mm
Master (outer) case gross weight11.8 kg
Products per master (outer) case16 pc(s)
Number of video streams2
