| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| Infrared (IR) cut-off filter | Y |
| Mounting type | Ceiling |
| Product colour | White |
| Form factor | Dome |
| LED indicators | Power |
| International Protection (IP) code | IP67 |
| IK code | IK10 |
| Weatherproof | Y |
| Country of origin | China |
| Lens viewing angle, horizontal | 35 - 115° |
| Lens viewing angle, vertical | 19 - 60° |
| Lens viewing angle, diagonal | 38.5 - 146° |
| Camera shutter speed | 1/3 - 1/100000 s |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.5 mm (1 / 2.5") |
| Progressive scan | Y |
| Zoom capability | Y |
| Optical zoom | 4.3x |
| Maximum aperture number | 2 |
| Focal length range | 2.8 - 12 mm |
| Night vision | Y |
| Night vision distance | 30 m |
| Maximum resolution | 3840 x 2160 pixels |
| Total megapixels | 8 MP |
| Video compression formats | H.264, H.265 |
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2560 x 1440, 2944 x 1656, 3840 x 2160 |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Digital Wide Dynamic Range (DWDR) | Y |
| Audio system | 2-way |
| Voice codecs | G.711a, G.711u, G.722.1, G.726, MP2L2 |
| Ethernet LAN | Y |
| Wi-Fi | N |
| Bluetooth | N |
| Networking standards | IEEE 802.3af |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP,SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6 |
| Quality of Service (QoS) support | Y |
| Built-in HDD | N |
| Card reader integrated | Y |
| Compatible memory cards | MicroSDHC, MicroSDXC |
| Maximum memory card size | 128 GB |
| Ethernet LAN (RJ-45) ports | 1 |
| Terminal block port | Y |
| Password protection | Y |
| Video motion detection | Y |
| Active tampering alarm | Y |
| IP address filtering | Y |
| Security algorithms | EAP-LEAP, EAP-MD5, EAP-TLS, HTTPS, TLS |
| Alert notification type | E-mail, Snapshot alert message, Text alert message |
| Intelligent Video Surveillance (IVS) system features | Abandoned object, Crossing line, Face detection, Intrusion, Missing object, Scene change |
| Digital watermark | Y |
| Web-based management | Y |
| Power source type | DC, PoE |
| Power consumption (typical) | 11.5 W |
| Power consumption (max) | 12.9 W |
| DC output voltage | 12 |
| Operating temperature (T-T) | -30 - 60 °C |
| Storage temperature (T-T) | 0 - 95 °C |
| Width | 133.1 mm |
| Depth | 153.4 mm |
| Height | 153.4 mm |
| Weight | 1.29 kg |
| Package width | 174 mm |
| Package depth | 173 mm |
| Package height | 244 mm |
| Package weight | 1.42 kg |
| Package type | Box |
| Number of cameras | 1 |
| Screws included | Y |
| Master (outer) cases per pallet (air) | 18 pc(s) |
| Pallet gross length | 80 cm |
| Pallet gross width | 120 cm |
| Pallet height (air) | 152 cm |
| Sustainability compliance | Y |
| Harmonized System (HS) code | 8525890000 |
| Master (outer) case width | 365 mm |
| Master (outer) case length | 372 mm |
| Master (outer) case height | 504 mm |
| Master (outer) case gross weight | 15 kg |
| Products per master (outer) case | 12 pc(s) |
