| Type | CCTV security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| Day/night mode | Y |
| Certification | CE/FCC |
| Mounting type | Ceiling |
| Product colour | White |
| Form factor | Dome |
| LED indicators | Power |
| International Protection (IP) code | IP67 |
| Weatherproof | Y |
| Country of origin | China |
| White balance | ATW |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
| Progressive scan | Y |
| Fixed focus | Y |
| Fixed focal length | 3.6 mm |
| Night vision | Y |
| Night vision distance | 30 m |
| LED type | IR |
| Number of illumination LEDs | 6 |
| Supported video modes | 1080p |
| Back Light Compensation (BLC) | Y |
| Highlight Compensation (HLC) | Y |
| Ethernet LAN | N |
| Wi-Fi | N |
| Bluetooth | N |
| Built-in HDD | N |
| Power source type | DC |
| Power consumption (typical) | 6 W |
| DC output voltage | 12 |
| DC output current | 1 A |
| Operating temperature (T-T) | -20 - 55 °C |
| Operating relative humidity (H-H) | 0 - 80% |
| Storage relative humidity (H-H) | 0 - 80% |
| Width | 92 mm |
| Depth | 73 mm |
| Height | 73 mm |
| Weight | 500 g |
| Package width | 120 mm |
| Package depth | 95 mm |
| Package height | 120 mm |
| Package type | Box |
| Number of cameras | 1 |
| Cables included | BNC |
| Harmonized System (HS) code | 85258900 |
| Master (outer) case width | 470 mm |
| Master (outer) case length | 420 mm |
| Master (outer) case height | 610 mm |
| Master (outer) case gross weight | 25.6 kg |
| Products per master (outer) case | 64 pc(s) |
