| Maximum data transfer rate | 1000 Mbit/s |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Jumbo frames support | Y |
| Jumbo frames | 9000 |
| Flow control support | Y |
| Fiber optic connector | SFP |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Power over Ethernet (PoE) ports quantity | 1 |
| Mean time between failures (MTBF) | 500000 h |
| Internal | N |
| LED indicators | Activity, Link, Power |
| DIN rail mounting | Y |
| Country of origin | Taiwan |
| Safety | IEC EN60950-1 |
| Certification | CE, FCC, VCCI, FCC Part 15 Subpart B Class A, CE EN 55022 Class A |
| Input voltage | 48 - 56 V |
| Power consumption (typical) | 2 W |
| Power over Ethernet (PoE) | Y |
| Total Power over Ethernet (PoE) budget | 30 W |
| Width | 32 mm |
| Depth | 81.5 mm |
| Height | 103.5 mm |
| Weight | 135 g |
| Operating temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Package width | 165 mm |
| Package depth | 65 mm |
| Package height | 215 mm |
| Package weight | 350 g |
| Manual | Y |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 350 mm |
| Master (outer) case length | 240 mm |
| Master (outer) case height | 560 mm |
| Master (outer) case gross weight | 6.6 kg |
| Products per master (outer) case | 16 pc(s) |
