| Maximum data transfer rate | 100 Mbit/s |
| Networking standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX |
| Fiber ethernet cabling technology | 100BASE-FX |
| Flow control support | Y |
| Auto MDI/MDI-X | Y |
| Auto-negotiation | Y |
| Store-and-forward | Y |
| Duplex system | Full, Half |
| Link Loss Carry Forward (LLCF) supported | Y |
| Link Loss Return (LLR) supported | Y |
| Cable types supported | Cat5 |
| Fiber optic connector | SX |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Maximum transfer distance | 20000 m |
| Wavelength-division multiplexing (WDM) | Y |
| Fiber cable diameters supported (core/cladding) | 8.3/125,9/125,10/125 µm |
| Internal | N |
| LED indicators | Activity, Link, Power |
| Product colour | Black |
| Country of origin | China |
| Certification | CE, FCC |
| Input voltage | 5 V |
| Input current | 1 A |
| Width | 94 mm |
| Depth | 70 mm |
| Height | 25 mm |
| Weight | 420 g |
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Package width | 235 mm |
| Package depth | 125 mm |
| Package height | 55 mm |
| Package weight | 914 g |
| Package type | Blister |
| AC adapter included | Y |
| Quick installation guide | Y |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 480 mm |
| Master (outer) case length | 360 mm |
| Master (outer) case height | 390 mm |
| Master (outer) case gross weight | 16.2 kg |
| Products per master (outer) case | 36 pc(s) |
