| Maximum data transfer rate | 100 Mbit/s |
| Networking standards | IEEE 802.3, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX |
| Jumbo frames support | Y |
| Jumbo frames | 9000 |
| Flow control support | Y |
| VLAN support | Y |
| Duplex system | Full, Half |
| Fiber optic connector | SFP |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Mean time between failures (MTBF) | 30000 h |
| Internal | N |
| LED indicators | Activity, FDX, Link, Power |
| Product colour | Black |
| Country of origin | China |
| Certification | FCC, CE |
| Input voltage | 100 - 240 V |
| Output voltage | 5 V |
| Output current | 2 A |
| Web-based management | Y |
| Hot-swap | Y |
| Width | 127 mm |
| Depth | 156 mm |
| Height | 32 mm |
| Weight | 700 g |
| Operating temperature (T-T) | -10 - 55 °C |
| Operating relative humidity (H-H) | 5 - 90% |
| Package width | 185 mm |
| Package depth | 275 mm |
| Package height | 62 mm |
| Package weight | 860 g |
| Package type | Box |
| Manual | Y |
| Sustainability certificates | RoHS |
| Harmonized System (HS) code | 85176990 |
| Master (outer) case width | 360 mm |
| Master (outer) case length | 480 mm |
| Master (outer) case height | 390 mm |
| Master (outer) case gross weight | 17.5 kg |
| Products per master (outer) case | 17 pc(s) |
