Level One LevelOne HDMI HVE-9200P über Cat5 Extender Kit HD PoE 100m

LEVEL ONE

HVE-9200P

Jauns

The HVE-92 series is a HDMI extension solution supports HDBaseT technology which transmits HDMI signal and multi-channel audio at resolution Ultra HD 4K x 2K (3840 x 2160 @ 30Hz) and 1080p Full HD up to 100m via Cat5e or Cat6 cable. The series of products are embedded with EDID priority management of HDMI outputs supports EDID Hotplug refreshing function. These products also provide Bi-Directional RS-232 and IR to control the connected devices from either source or display location. All the features are made to simplify installation and reduce costs, but at the same time providing exceptional video and audio quality. The HVE-92 series is the perfect solution for Digital Signage, trade shows, home theater installations, medical facilities, and other public exhibitions. - IEEE 802.3af PoE compliant to simplify deployment and installation - Simple Plug and Play installation - Built-in EDID Hot Plug Detection (HPD) - HDMI outputs with EDID management - Transmission distance of up to 100m for HDMI(4k2k), IR and RS-232 - Bi-Directional RS-232 pass through & IR Control - Supports video resolutions up to 3840 x 2160 (4K x 2K) @ 30Hz - HDMI and HDCP complaint - Supports Dolby TrueHD, DTS-HD Master Audio, Dolby Digital Plus, LPCM 7.1 audio - Supports 3D, CEC & Lip Sync pass-through - Screw-in power socket for added safety

TypeAV transmitter & receiver
Maximum resolution3840 x 2160 pixels
Cable types supportedCat5, Cat5e, Cat6
Maximum transfer distance100 m
LED indicatorsY
Supported video modes1080p
Bandwidth10.2 Gbit/s
MaterialMetal
Colour depth48 bit
Product colourGrey
RJ-45 input ports1
HDMI in1
Number of HDMI outputs1
RS-232 input ports2
DC-in jackY
Operating voltage12 V
Current2 A
Power over Ethernet (PoE)Y
Width125 mm
Depth85 mm
Height40 mm
Receiver dimensions (WxDxH)85 x 125 x 40 mm
Transmitter dimensions (WxDxH)85 x 125 x 40 mm
Package dimensions (WxDxH)300 x 170 x 120 mm
Package width300 mm
Package depth170 mm
Package height120 mm
Package weight1.45 kg
AC adapter includedY
Cables includedAC
ManualY
