LEVEL ONE

POI-5001

Jauns

POI-5001 is a single port, high-power 60W PoE PSE solution for remote PoE PD devices. Generating up to 60W through 8 pins, POI-5001 supplies remote power for new applications such as wireless access points, pan-tilt-zoom (PTZ) IP cameras, lighting, panel display for digital signage and video-phones. It complies to IEEE 802.3bt PoE++ standards to deliver 60W on both end-point and midspan pairs with a total power of 60W PoE output. It can work with 10/100Base-T networking devices and emerging 1000Base-T devices such as Wi-MAX and wireless IEEE 802.11n access points.Key Features - PoE supplies up to 60W of power feeding on 4 pairs - Auto-detection and protection of non-standard PoE devices - IEEE 802.3af/at PoE compliant to simplify deployment and installation

Ethernet interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
Power over Ethernet (PoE)Y
Networking standardsIEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Product colourBlack
LED indicatorsPower
CertificationRoHS
Country of originTaiwan
Ethernet LAN (RJ-45) ports2
Output power60 W
AC adapter input voltage100 - 240 V
Input voltage56 V
Power consumption (typical)2 W
Operating temperature (T-T)0 - 40 °C
Width180 mm
Depth71 mm
Height37 mm
Weight530 g
Package width210 mm
Package depth125 mm
Package height60 mm
Package weight800 g
Package typeBox
Number of products included1 pc(s)
Power cord includedY
Harmonized System (HS) code85044095
Master (outer) case width580 mm
Master (outer) case length435 mm
Master (outer) case height277 mm
Master (outer) case gross weight33 kg
Products per master (outer) case40 pc(s)
