Neomounts by Newstar WAH 32"-55" 1TFT 2Gelenk schw. Max.35

NEOMOUNTS BY NEWSTAR

WL40-540BL14

Jauns

The Neomounts by Newstar WL40-540BL14 is a full motion wall mount for flat screens up to 55" with a maximum weight capacity of 35 kg. The versatile tilt (14°) and swivel (30°) technology allows you to create the optimum viewing angle. The mount can be levelled for the perfect installation.The WL40-540BL14 has a depth of 4,6-30,8 cm and is suitable for screens that meet VESA hole pattern 100x100 to 400x400 mm.The mount features a nifty Easy-release system, that allows you to attach the TV in a wink of an eye. The mount is equipped with cable management, to secure any loose cables on the back of the screen.

Maximum weight capacity35 kg
Maximum screen size139.7 cm (55")
Mounting typeWall
Minimum VESA mount100 x 100 mm
Maximum VESA mount400 x 400 mm
Minimum screen size81.3 cm (32")
Panel mounting interface200 x 100,200 x 200,200 x 300,200 x 400,300 x 300,300 x 200,400 x 200,400 x 400,400 x 300
Number of displays supported1
Height adjustmentN
Tilt adjustmentY
Tilt angle range-2 - 12°
Swivel angle30°
Cable managementY
Distance to the wall (max)30.8 cm
Distance to the wall (min)4.6 cm
Product colourBlack
Quantity per pack1 pc(s)
Mounting kitY
Width433 mm
Depth46 mm
Height433 mm
Package width442 mm
Package depth229 mm
Package height56 mm
Master (outer) case width462 mm
Master (outer) case length300 mm
Master (outer) case height250 mm
Master (outer) case net weight17.5 kg
Products per master (outer) case5 pc(s)
Harmonized System (HS) code7326909890
Products per pallet (EU)150 pc(s)
Country of originChina
Package net weight3.7 kg
