Level One LevelOne Switch 8x GE GEP-0812W90 19" 90W 4xPoE

LEVEL ONE

GEP-0812W90

New

The LevelOne GEP-0812 series provides 4 x 10/100/1000Mbps and 4 x 10/100/1000Mbps PoE Plus ports. This switch is IEEE 802.3af/at compliant, and provides power and data over a single Ethernet cable to any PoE device, with total power budget of 61.6W / 90W / 120W, up to 30W per port. Ideal for desktops and it is also 19-inch rack-mountable, which provides convenient and flexible installation. The GEP-0812 series is designed for small businesses that prefer an affordable solution for PoE deploying infrastructure.- Auto-detection and protection of non-standard PoE devices - Supports 8K MAC address auto-learning and auto-aging - IEEE 802.3af/at PoE compliant to simplify deployment and installation - 9K jumbo frames to increase data transfer rates - 11-inch metal housing with 19-inch rackmount kit included - 1000Mbps full-duplex, 10/100Mbps full/half-duplex, auto-negotiation, auto-MDI/MDIX

Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity8
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
Full duplexY
Flow control supportY
Auto-negotiationY
MAC address auto-learning supportedY
MAC address auto-aging supportedY
MAC address table8000 entries
Switching capacity16 Gbit/s
Store-and-forwardY
Static routeY
Jumbo frames supportY
Jumbo frames9000
Packet forwarding rate (1 Gbps)1488000 pps
Packet forwarding rate (100 Mbps)148000 pps
Packet forwarding rate (10 Mbps)14880 pps
DHCP featuresDHCP snooping, DHCP relay
SSH/SSL supportY
Rack mountingY
Product colourGrey
Housing materialMetal
LED indicatorsActivity, PoE, Power
Country of originTaiwan
CertificationFCC, CE, RoHS
Buffer size128 KB
sFlowY
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current2 A
Power consumption (typical)90 W
Power protection featuresOver current, Short circuit
Power over Ethernet (PoE)Y
Power over Ethernet plus (PoE+) ports quantity4
Power over Ethernet (PoE) power per port30 W
Total Power over Ethernet (PoE) budget85 W
Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)10 - 90%
Width280 mm
Depth125.5 mm
Height44 mm
Weight1.5 kg
Cables includedAC
Quick start guideY
Package typeBox
Rack mount kitY
Package width235 mm
Package depth83 mm
Package height377 mm
Package weight1.7 kg
Master (outer) case width246 mm
Master (outer) case length392 mm
Master (outer) case height525 mm
Harmonized System (HS) code85176990
Master (outer) case gross weight10.2 kg
Products per master (outer) case6 pc(s)
