Level One LevelOne Switch 26x GE GEP-2651 2xGSFP 19" 185W 24xPoE+

LEVEL ONE

GEP-2651

New

GEP-2651 Web Smart Gigabit PoE Switch is a next-generation Ethernet Switch offering powerful L2 features, Layer 3 Static Route, better PoE functionality and usability that delivers the cost-effectively business and transports Ethernet services via fiber or copper connections. GEP-2651 delivers 24 (10M/100M/1G) RJ45/PoE+ (Support 802.3at/af, and total up to 185W) ports and 2 Combo GbE RJ45/SFP ports. GEP-2651 provides high HW performance and environment flexibility for SMBs and Enterprises. GEP-2651 is ideal to deliver management simplicity, optimum user experience, and lower total cost of ownership. The embedded Device Managed System is designed to be extremely easy-to-use/manage/install IP Phone, IP Cam, or Wifi-AP for Enterprise Applications.Key Features - 24 PoE-Plus Gigabit Ethernet ports and 2 Gigabit SFP slots - QoS control for traffic prioritization and bandwidth management - DHCP Client/Server - Supports IPv4/IPv6 network operation - Minimize carbon footprint with advanced energy efficient technology (IEEE 802.3az) - IEEE 802.1d/w/s Spanning Tree Protocol (STP) and port mirroring - IP Multicast Filtering through IGMP Snooping V1 / V2 / V3 - Supports port-based VLAN, IEEE 802.1Q VLAN Tagging - IEEE 802.3ad LACP for auto port aggregation

Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportY
Web-based managementY
System event logY
Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity24
Combo SFP ports quantity2
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3z
Copper ethernet cabling technology100BASE-TX, 1000BASE-T
Port mirroringY
Flow control supportY
Link aggregationY
Broadcast storm controlY
Spanning tree protocolY
Cable length detectionY
MAC address auto-learning supportedY
MAC address auto-aging supportedY
VLAN supportY
Virtual LAN featuresTagged VLAN, MAC address-based VLAN, Port-based VLAN
Number of VLANs256
Fiber ethernet cabling technology1000BASE-X
MAC address table8000 entries
Switching capacity52 Gbit/s
Forwarding rate38.7 Mpps
Store-and-forwardY
Static routeY
Jumbo frames supportY
Jumbo frames9600
DHCP featuresDHCP server, DHCP snooping, DHCP client
Access Control List (ACL)Y
IGMP snoopingY
Security algorithms802.1x RADIUS
Static port securityY
Loop protectionY
BPDU filtering/protectionY
Supported network protocolsIPv4/IPv6
Rack mountingY
Product colourBlack
Reset buttonY
LED indicatorsActivity, Link, PoE, Speed
Country of originTaiwan
SafetyUL 60950-1, 2nd Edition, 2014-10-14, CAN/CSA C22.2 No. 60950-1-07, 2nd Edition, 2014-10
CertificationCE, FCC Part 15 Class A, RoHS
Internal memory128 MB
Flash memory32 MB
Firmware upgradeableY
Buffer size512 KB
Mean time between failures (MTBF)211272 h
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)18.29 W
Power over Ethernet (PoE)Y
Power over Ethernet plus (PoE+) ports quantity24
Power over Ethernet (PoE) power per port30 W
Total Power over Ethernet (PoE) budget185 W
Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)10 - 90%
Width442 mm
Depth211 mm
Height44 mm
Weight3.1 kg
Cables includedAC
Quick start guideY
ManualY
Package width300 mm
Package depth520 mm
Package height90 mm
Package weight3.5 kg
Master (outer) case width482 mm
Master (outer) case length540 mm
Master (outer) case height324 mm
Harmonized System (HS) code85176990
Master (outer) case gross weight21 kg
Products per master (outer) case5 pc(s)
