Level One LevelOne Switch 48x GE GTL-5291 4x10GSFP+19"

LEVEL ONE

GTL-5291

New

The LevelOne GTL-5291 includes high-performance Gigabit Ethernet Layer3 switches featuring 52 ports; 48 10/100/1000BASE-T ports, 4 10G SFP+ ports, Supports L3 management, such as OSPF, RIP, QoS, VLAN, MSTP, Multi-brocast, ports management. The switch is ideal for high-performance server aggregations, such as enterprise data centers, where it can connect high-end or network-attached file servers through fiber ports. It can also deployed as a backbone upgrade, or to provide Gigabit-to-the-desktop for power users. This switch is packed with features and is a cost-effective solution that brings continuous availability, enhanced security, and advanced QoS to the network edge, while maintaining simplicity of management.

Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportY
Basic switching RJ-45 Ethernet ports quantity48
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity48
SFP+ module slots quantity4
Console portRJ-45
Power connectorAC-in jack
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportY
Copper ethernet cabling technology10BASE-T, 100BASE-T, 100BASE-TX, 1000BASE-T
Ethernet LAN data rates10,100,1000 Mbit/s
VLAN supportY
Fiber ethernet cabling technology1000BASE-LHX, 1000BASE-LX, 1000BASE-SX, 1000BASE-ZX
MAC address table8000 entries
Rack mountingY
StackableN
Form factor1U
Product colourBlack
LED indicatorsActivity, Link, Power
Country of originChina
FanlessN
Power sourceAC
Power supply includedY
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power over Ethernet (PoE)N
Width442 mm
Depth320 mm
Height44 mm
Weight6 kg
Cables includedAC
Quick start guideY
Package typeBox
Rack mount kitY
Package width530 mm
Package depth460 mm
Package height90 mm
Package weight7.2 kg
Harmonized System (HS) code85176990
