Digitus 8 Port Gigabit Switch, 10 Inch, Managed

Digitus

DN-80117

New

L2 managed Gigabit Ethernet Switch 8-port, 10 inch

L2+ managed Gigabit Switch - suitable for installation in 10-inch housing

8-Port 10/100/1000 Mbps
Network standards: IEEE802.3, IEEE802.3u, IEEE802.3ab
IEEE802.3x full-duplex flow control & IEEE 802.3ab link aggregation
Management interfaces: WEB, SNMP, SSH, CLI, Telnet
Port Control, Port Isolation, Loop Detection, Port Mirroring
Backplane bandwidth: 16 Gbps
VLAN features
L2+ layer features

The 8-port Gigabit L2+ Switch is designed for the networks of small to mid-sized companies. With special features such as port control, port mirroring, VLAN functions and multicast support, the switch is optimally tailored to the application convergence needs of mid-sized networks. Based on ASIC integration technology, non-blocking IP switching solutions are supported with gigabit speed. The switch can be used as a desktop switch or for installation in 10-inch housing. 8 gigabit ports are integrated that can be configured for specific requirements using various interfaces. The installation height is one rack unit.

Number of ports: 8
Ethernet speed: Gigabit
Industrial usage: false
Installation type: 10 inch, Desktop
Managed: true
Outdoorsuitable: false
PoE (Power over Ethernet): false
Protection against vanadlism: false
VLAN: true
Number of ports: 8 x 10/100/1000Base-TX RJ45
Standards: IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3x full-duplex flow control, IEEE802.3ab link aggregation
Forwarding rate: 10/100/1000 Mbps
LED displays: Power, Link/Act
Backplane bandwidth: 16G
Forwarding capacity: 11.9 Mpps
Jumbo frame size: 16 K
MAC addresses: 8K
Port features: Port Control, Port Isolation, Port Loop Detection
Port mirroring: Multi to 1 Sniffer
VLAN: Port-based & 802.1q Tag-based VLANs
Link aggregation: 8 groups
Rate limit: 64kbps
Spanning tree: Supports STP, RSTP, MSTP
Ring protocol: Supports EAPS
Multicast: Supports 256 multicast groups & IGMP snooping for multimedia applications
Supports Static ARP & Static Routing, up to 32 VLAN interfaces
QoS: 4 lines per port, scheduling algorithm: WRR, SP, WFQ, port-based, MAC-based, 802.1p, DSCP classification
ACL: Standard IP, Extend IP, MAC IP, ARP, 512 entries
Security: MAC-based authentication, AAA/RADIUS authentication, WEB/Telnet password protection, Accessing privilege mode password protection
Supports SMNP
Supports ICMPv6, IPv6 Neighbor Discovery, MLD Snooping, IPv6 Telnet
Management interfaces: WEB, SNMP, CLI, Telnet, TACACS+, RMON
Power consumption: 15W max.
Operating voltage: 100 - 240 V AC, 50/60 Hz, integrated power adapter (IEC C13 plug for non-heating appliances)
Operating temperature: 0 °C to 40 °C
Storage temperature: -10 °C to +70 °C
Operating humidity: 20% - 85% (non condensing)
Housing: Metal (with protective conductor terminal)
Dimensions: W 250 x D 150 x H 44 mm
Weight: 1.140 kg (without packaging)

Package content:
10 Inch 8 Port Gigabit Ethernet Switch, L2+ Managed
Power cord connection cable with coupling for non-heating appliances (IEC C13)
QIG

Platums(cm)24
Grums(cm)7
Augstums(cm)32
Svars(kg)1.6
Tilpums(cm3)5376
Izcelsmes valstsCN
