Digitus 24-Port Gigabit Switch, 19 Inch, Managed, 2 Uplinks

Digitus

DN-80221-3

New

L2 managed Gigabit Ethernet Switch 24-port + 2 combo and 2 SFP uplink port

Highest bandwidth and performance for professional demands. Superior manageability via WebUI!

24 x 10/100/1000BaseTX ports
2 x Uplink RJ45/SFP combo ports
2 x SFP uplink ports
1 x RJ45 console port integrated
Layer-2 features configurable via WebUI
Extensive Layer 2 features for optimal configuration
L2 features: VLAN, Link-Aggregation, Port-Mirroring, Port-Trunking, SNMP Netzwerk Management, QoS-/CoS-Anwendungen, STP/RSTP/MSTP
Installation in 19" server and wall cabinets possible

The DIGITUS® Gigabit Ethernet Layer 2 switches with 24 x RJ45 Gigabit ports and 4 uplink ports are designed for medium to large network systems. For the uplink ports, you have the choice of 2 x SFP/RJ45 combo ports and 2 pure SFP uplink ports. They provide smart features that are ideal for simple QoS/CoS applications and the 19'' size makes an uncomplicated integration into your network possible. The switches are a great choice to improve the performance and efficiency of your network.

Number of ports: 24
Ethernet speed: Gigabit
Industrial usage: false
Installation type: 19 inch, Desktop
Managed: true
Number of ports (Uplink): 4
Outdoorsuitable: false
PoE (Power over Ethernet): false
Protection against vanadlism: false
Uplink port connection: RJ45/SFP
VLAN: true
24 x RJ45 ports (1000Mbps)
2 x RJ45/ SFP combo ports for fiber optic connection or Ethernet
2 x SFP uplink ports for SFP modules
1 x RJ45 console port
Compatible with following standards: IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.3z and 802.3ad - Auto MDI/MDI-X Funktion
8K MAC addresses
QoS support layer 4 classification
Port mirroring for efficient network surveillance
Port Trunk for bandwidth aggregation
VLAN for performance and security
802.1x Port Authentication
SNMP Network Management
Built-in Web-based management
Surge protection +/- 6 kV
Dimensions: 440 x 208 x 44 mm (WxDxH)

Package content:
1 x Gigabit Ethernet Layer 2 Switch, 24 port
1 x Mounting accessories for 483 mm (19")
1 x QIG
1 x Power cord

Platums(cm)30
Grums(cm)56.2
Augstums(cm)9
Svars(kg)2.145
Tilpums(cm3)15174
Izcelsmes valstsCN
