LINDY 4 Port HDMI 18G, USB 2.0 & Audio KVM Switch

Lindy

32810

New

Controls four HDMI equipped PCs from a single keyboard, mouse and monitor Switch via the unit's push button or keyboard hotkeys Supports HDMI 18G resolutions up to 4K@60Hz 4:4:4 with HDR 3.5mm stereo audio ports to connect microphone, speakers or headphones 2 year warrantyA KVM switch allows an operator to conveniently control and manage multiple devices, such as PCs and servers, from a single keyboard, mouse and display console.The Lindy 4 Port HDMI 4K60, USB 2.0 & Audio KVM Switch is a compact solution for providing access and control over four HDMI equipped PCs from a single keyboard, mouse and monitor setup.Support for resolutions up to 4K Ultra HD 60Hz ensures the highest image quality, perfect for demanding graphical content in gaming setups, video editing or quad system control workstations. The additional support for High-Dynamic Range ensures video content can be seen with enhanced brightness, greater contrasts and a much wider colour gamut. The audio output ports on the main unit also allow users to connect headphones or speakers to add immersive 2CH audio and a microphone, pressing the Audio On/Off button on the front panel mutes these devices. These ports are not connected to the HDMI signal but to a built-in USB converter while an additional USB device  such as a printer, scanner or hard drive can be connected to the additional USB port on the front panel.The KVM switch features two switching options including push buttons on the unit and keyboard hotkeys provide simple, reliable control for the user, great for both professional and first time users.

Number of computers controlled4
Keyboard port typeUSB
Mouse port typeUSB
Video port typeHDMI
Console ports3.5mm headphone, HDMI, USB A
HDMI ports quantity4
HDMI version2.0
USB 2.0 Type-B ports quantity4
Console USB ports quantity3
Audio connectionsY
Headphone outputs2
HD type4K Ultra HD
Maximum resolution4096 x 2160 pixels
Video bandwidth60 Hz
HDCPY
Rack mountingN
Product colourBlack
Housing materialMetal
LED indicatorsStatus
Push buttonY
Hot keysY
CertificationCE, UKCA, FCC, RoHS, REACH & California Proposition 65
Built-in displayN
DC input voltage5 V
Output current2 A
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-10 - 60 °C
Operating relative humidity (H-H)5 - 80%
Width231 mm
Depth108 mm
Height23 mm
Weight689 g
Package width292 mm
Package depth238 mm
Package height55 mm
Package weight988 g
Package typeBox
Cables includedDC
Quick installation guideY
ManualY
Harmonized System (HS) code85176200
