Level One LevelOne WL-Antenne WAN-7100 10,5dBi 2,4 GHz Outd

LEVEL ONE

WAN-7100

Jauns

The LevelOne WAN-7100 10.5dBi directional dual polarization antenna kit is designed for indoor / outdoor wireless connections. With array pattern located at +45° and -45° polarization, you can improve signal strength in crowded areas where lot of interferences occur. This antenna kit comes with antenna, 3m UL-168 jump cables and has been tested for interoperating with LevelOne 2T2R MIMO access points. It provides Indoor/Outdoor building-to-building bridges and can be used with other wireless products, which are equipped with reverse SMA male connector and detachable antennas.- Wi-Fi IEEE 11b/g/n band 2.4GHz global compatibility - 2T2R MIMO high-throughput and diversity with 10.5dBi high-gain performance - Dual-Polarization to avoid interference - Easy to install on the wall surface - Wideband frequency performance enables future growth and increases flexibility - Includes UL-168 3m cables for wireless device with SMA connectors

Antenna gain level (max)10.5 dBi
Frequency band2.3 - 2.7 GHz
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Impedance50 Ω
Horizontal beam width67°
Vertical beam width37°
Antenna typeDirectional antenna
Antenna connector typeSMA
PolarizationDual polarization
Voltage Standing Wave Ratio (VSWR)2.0:1
Power handling10 W
MountingWall
PurposeIndoor & outdoor
Product colourWhite
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)0 - 95%
Width93 mm
Depth330 mm
Height21.4 mm
Weight200 g
Quantity per pack1 pc(s)
Cables includedCoaxial
Harmonized System (HS) code85177100
