Level One LevelOne SFP Transceiver 1.25G Single-Mode 10km 1310nm

LEVEL ONE

SFP-4210

Jauns

LevelOne SFP-4210 is a high performance and cost-effective single-mode SFP transceiver. Intended for use with Gigabit Ethernet, it provides up to 1.25 Gbps bidirectional data transfer rate on a single duplex fiber core. For use with 9 and 125 micron fiber cables, it can reach a distance of up to 10km. The SFP-4210 transceiver operates using a wavelength of 1310nm with a FP Laser Diode light source and has an LC port.This Hot-swappable SFP transceiver offers the latest Industrial standard in full-duplex Ethernet connectivity and withstand under wide range temperature operation.

SFP transceiver typeFiber optic
Maximum data transfer rate1250 Mbit/s
Interface typeSFP
Single-mode fiber (SMF) supportedY
Multi-mode fiber (MMF) supportedN
Fiber optic connectorLC
Fiber cable diameters supported (core/cladding)9/125 µm
Maximum transfer distance10000 m
Wavelength1310 nm
Tx power (min)-9.5 dBmW
Tx power (max)-3 dBmW
Rx power (min)-25 dBmW
Rx power (max)2 dBmW
Networking standardsIEEE 802.3z
Copper ethernet cabling technology1000BASE-LX
Duplex systemFull
Digital Diagnostics Monitoring (DDM)Y
Product colourSilver
Hot-swapY
Country of originChina
CertificationCE, FCC
Maximum voltage3.47 V
Maximum current0.3 A
Power consumption (typical)0.8 W
Operating temperature (T-T)0 - 70 °C
Storage temperature (T-T)-40 - 85 °C
Operating relative humidity (H-H)0 - 85%
Width14 mm
Depth57 mm
Height12 mm
Weight20 g
Number of products included1 pc(s)
User guideY
Package width65 mm
Package depth106 mm
Package height20 mm
Package weight39 g
Package typeBox
Sustainability certificatesRoHS
Pallet gross length80 cm
Pallet gross width120 cm
Pallet height (air)166.9 cm
Products per pallet35 pc(s)
Master (outer) case width310 mm
Master (outer) case length375 mm
Harmonized System (HS) code85369010
Master (outer) case height268 mm
Master (outer) case gross weight6.67 kg
Products per master (outer) case150 pc(s)
