| Basic switching RJ-45 Ethernet ports quantity | 9 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Fast Ethernet (copper) ports quantity | 8 |
| Gigabit Ethernet (copper) ports quantity | 1 |
| SFP module slots quantity | 1 |
| Power connector | DC-in jack |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| 10G support | N |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Full duplex | Y |
| Auto MDI/MDI-X | Y |
| MAC address table | 4000 entries |
| Switching capacity | 5.6 Gbit/s |
| Store-and-forward | Y |
| Static route | Y |
| Packet forwarding rate (1 Gbps) | 1488000 pps |
| Packet forwarding rate (100 Mbps) | 148000 pps |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| DHCP features | DHCP snooping, DHCP relay |
| SSH/SSL support | Y |
| Rack mounting | N |
| Product colour | Grey |
| LED indicators | Activity, PoE, Power |
| On/off switch | Y |
| Country of origin | Taiwan |
| Certification | CE, FCC, RoHS |
| sFlow | Y |
| Input voltage | 56 V |
| Power consumption (typical) | 90 W |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 82 W |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 10 - 90% |
| Width | 188 mm |
| Depth | 118 mm |
| Height | 38 mm |
| Weight | 1.5 kg |
| Cables included | AC |
| AC adapter included | Y |
| Package type | Box |
| Package width | 222 mm |
| Package depth | 146 mm |
| Package height | 78 mm |
| Package weight | 1.7 kg |
| Master (outer) case width | 420 mm |
| Harmonized System (HS) code | 85176990 |
| Products per master (outer) case | 10 pc(s) |
