Level One LevelOne Switch 50x FE FGU-5021 2xGSFP 19"

Kods FGU-5021

Condition: Jauns

Vairāk informācijas

- 10/100Mbps, full/half-duplex, auto-negotiation, auto-MDI/MDIX - 9K jumbo frames to increase data transfer rates - Supports 8K MAC address auto-learning and auto-aging - 19-inch metal housing - Quick and easy installationFast connections and fiber distances FGU-5021 is a 48-port Fast Ethernet Switch (10/100 Mbps) that gives you a high-performance, low-cost, easy-to-use, solution to expand your network reach. With 2 Gigabit ports and 2 SFP Port , you’re able to connect to other networks for flexible and powerful deployment options.Plug and Play, Flexible and Easy GSW-5150 is plug-and-play so no configuration is required. Providing auto MDI/MDI-X cable detection on all ports eliminates the need for crossover cables or Uplink ports. Each port can be used as general ports or Uplink ports, and any port can be simply plugged into a server, a hub, a router or a switch, using a straight cable or crossover cable. Diagnostic LEDs which display link status and activity, allowing you to quickly detect and correct problems on the network.

Basic switching RJ-45 Ethernet ports quantity	50
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Fast Ethernet (copper) ports quantity	48
Gigabit Ethernet (copper) ports quantity	2
Combo SFP ports quantity	2
Fiber optic connector	SFP
Console port	RJ-45
Networking standards	IEEE 802.3, IEEE 802.3az, IEEE 802.3u
10G support	N
Copper ethernet cabling technology	10BASE-T, 100BASE-T, 1000BASE-T, 1000BASE-TX
Full duplex	Y
Auto MDI/MDI-X	Y
Auto-negotiation	Y
MAC address auto-learning supported	Y
MAC address auto-aging supported	Y
Fiber ethernet cabling technology	100BASE-X, 1000BASE-X
MAC address table	8000 entries
Switching capacity	13.6 Gbit/s
Store-and-forward	Y
Jumbo frames support	Y
Jumbo frames	9000
Packet buffer memory	4 MB
Rack mounting	Y
Product colour	Grey
Housing material	Metal
LED indicators	Activity, Link, Power
Country of origin	China
Certification	CE/FCC
Internal memory	16 MB
Power supply included	Y
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	28.6 W
Power over Ethernet (PoE)	N
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Width	44 mm
Depth	230 mm
Height	440 mm
Weight	2.7 kg
Cables included	AC
Quick start guide	Y
Package type	Gift box
Package width	375 mm
Package depth	100 mm
Package height	510 mm
Package weight	2.82 kg
Master (outer) case width	520 mm
Master (outer) case length	395 mm
Master (outer) case height	535 mm
Harmonized System (HS) code	85176990
Master (outer) case gross weight	13.8 kg
Products per master (outer) case	5 pc(s)
