Level One LevelOne Konverter GVM-1000 10/100/1000TX>1000FX 500m

LEVEL ONE

GVM-1000

Jauns

GVM-1000 series is remote Managed Gigabit Ethernet fiber media converter with OAM functions developed by our company. It can convert Ethernet signal between 10/100/1000Base-T and 1000Base-X, It supports both half-duplex and full-duplex operations and a variety of fiber options.Remote devices can be managed by fiber-connected OAM media converter or OAM switch when deployed as a stand-alone solution. It incorporates an easy to use Web user interface for operation, administration and maintenance, both locally and remotely. By offering IEEE802.3ah OAM compliance, this converter can be linked to any IEEE802.3ah compliant fiber switch and support loop back and dying gasp functions. All functions of this converter and the remotely connected converter can be configured and monitored via Web management, including bandwidth control, duplex, speed and VLAN configuration.Key Features - IEEE 802.3x Flow Control protects against lost packets for reliable data transmission - Web-based and SNMP Management - Built-in LFP (Link Fault Pass-through) (LLCF/LLR) Technology - Supports VLAN (tag-based, Q-in-Q)

Maximum data transfer rate1000 Mbit/s
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Ethernet interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
Jumbo frames supportY
Jumbo frames9000
Flow control supportY
VLAN supportY
Store-and-forwardY
Duplex systemFull, Half
Link Loss Carry Forward (LLCF) supportedY
Link Loss Return (LLR) supportedY
Fiber optic connectorSFP
Connectivity technologyWired
Ethernet LAN (RJ-45) ports1
Fiber ports quantity1
Mean time between failures (MTBF)30000 h
InternalN
LED indicatorsActivity, FDX, Link, Power
Product colourBlack
Country of originChina
CertificationCE, FCC
Input voltage100 - 240 V
Output voltage5 V
Output current2 A
Web-based managementY
Hot-swapY
Width127 mm
Depth156 mm
Height32 mm
Weight700 g
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)5 - 90%
Package width185 mm
Package depth275 mm
Package height62 mm
Package weight860 g
ManualY
Sustainability certificatesRoHS
Harmonized System (HS) code85176990
Master (outer) case width360 mm
Master (outer) case length480 mm
Master (outer) case height390 mm
Master (outer) case gross weight17.5 kg
Products per master (outer) case17 pc(s)
