| Maximum data transfer rate | 100 Mbit/s |
| Converter input interface | 10Base-T, 100Base-TX |
| Converter output interface | 100Base-FX |
| Networking standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Flow control support | Y |
| Auto MDI/MDI-X | Y |
| Auto-negotiation | Y |
| Duplex system | Full, Half |
| Fiber optic connector | ST |
| Connectivity technology | Wired |
| Ethernet LAN (RJ-45) ports | 1 |
| Fiber ports quantity | 1 |
| Maximum transfer distance | 2000 m |
| Fiber mode structure | Multi-mode |
| Internal | N |
| LED indicators | Activity, Link, Power |
| Product colour | Black |
| Housing material | Aluminium |
| Country of origin | Taiwan |
| Certification | FCC Part 15 Subpart B Class A CE EN 55022 Class A FCC Part 15 Subpart B Class A, CE EN 55022 Class A EN61000-4-2 (ESD) Level 3 EN61000-4-3 (RS) Level 2 EN61000-4-4 (EFT) Level 2 EN61000-4-5 (Surge) Level 2 EN61000-4-6 (CS) Level 2 EN 61000-4-8 (PFMF) Level 1 UL508 (Pending) EN 50121-4 (Pending) IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6 |
| Input voltage | 12 - 60 V |
| Power consumption (typical) | 1.44 W |
| Width | 59 mm |
| Depth | 49 mm |
| Height | 36 mm |
| Weight | 90 g |
| Operating temperature (T-T) | -40 - 75 °C |
| Storage temperature (T-T) | -40 - 75 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Package width | 160 mm |
| Package depth | 105 mm |
| Package height | 65 mm |
| Package weight | 260 g |
| Package type | Box |
| Quick installation guide | Y |
| Sustainability certificates | RoHS |
| Harmonized System (HS) code | 85176990 |
