Level One LevelOne Switch 24x GE GTP-2871 4x10GSFP+19" 400W 24xPoE+

LEVEL ONE

GTP-2871

New

The GTP-2871 is LevelOne latest generation of 28-Port L3 Lite Managed Gigabit PoE Switch, with 4 10G SFP+ port connectivity. offers powerful L2 and L3 Lite features, better PoE functionality with 400W PoE power budget and usability, The switch also supports the most advanced IPv6 management,IPv6 security, and IPv6 multicast control in accordance with the growth of IPv6 deployment.The GTP-2871 PoE-enabled switches features an IEEE 802.3af/at certified. are ideal for businesses looking to power VoIP phones, wireless access points or network cameras. The GTP-2871 24-port PoE Switch supports up to 30 W of power output giving you flexibility in power allocation for a variety of powered devices enabling you to scale your operations to meet business growth, operational cost savings, and ease of management.

Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportY
Web-based managementY
Traffic classificationY
ARP inspectionY
Configuring Location Settings (CLI)Y
System event logY
Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity24
SFP+ module slots quantity4
Fiber ports quantity4
Fiber optic connectorSFP+
Power connectorAC-in jack
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z
10G supportY
Port mirroringY
Full duplexY
Link aggregationY
Broadcast storm controlY
Rate limitingY
Spanning tree protocolY
Ethernet LAN data rates10,100,1000 Mbit/s
MAC address table16000 entries
Switching capacity128 Gbit/s
Forwarding rate95.232 Mpps
Store-and-forwardY
Static routeY
Maximum data transfer rate10 Gbit/s
Jumbo frames supportY
Jumbo frames12000
Packet buffer memory1.5 MB
DHCP featuresDHCP relay, DHCP server, DHCP snooping
Access Control List (ACL)Y
IGMP snoopingY
IGMP proxyY
AuthenticationMAC-based authentication
Authentication typeRADIUS
Queue scheduling algorithmsPriority queuing (PQ), Weighted Round Robin (WRR)
Multicast supportY
Rack mountingY
Product colourGrey
Housing materialMetal
Reset buttonY
LED indicatorsY
Country of originChina
CertificationCE
Virtual stacking (units)4
Internal memory512 MB
Flash memory32 MB
Firmware upgradeableY
Plug and PlayY
Mean time between failures (MTBF)150000 h
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current6 A
Power consumption (typical)468.2 W
Power over Ethernet (PoE)Y
Power over Ethernet (PoE) power per port30 W
Total Power over Ethernet (PoE) budget400 W
Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 95%
Width330 mm
Depth440 mm
Height44.5 mm
Weight4.48 kg
Cables includedAC
Quick start guideY
Rack mount kitY
Rubber feetY
Resource CDY
Package width390 mm
Package depth596 mm
Package height80 mm
Package weight6 kg
Sustainability certificatesRoHS
Harmonized System (HS) code85176990
