Level One LevelOne Switch 52x GE GTP-5271 4x10GSFP+19" 400W 48xPoE

LEVEL ONE

GTP-5271

New

The GTP-5271 is LevelOne latest generation of 52-Port L3 Lite Managed Gigabit PoE Switch, with 4 10G SFP+ port connectivity. offers powerful L2 and L3 Lite features, better PoE functionality with 400W PoE power budget and usability, The switch also supports the most advanced IPv6 management,IPv6 security, and IPv6 multicast control in accordance with the growth of IPv6 deployment.The GTP-5271 PoE-enabled switches features an IEEE 802.3af/at certified. are ideal for businesses looking to power VoIP phones, wireless access points or network cameras. The GTP-5271 48-port PoE Switch supports up to 30 W of power output giving you flexibility in power allocation for a variety of powered devices enabling you to scale your operations to meet business growth, operational cost savings, and ease of management.

Switch typeManaged
Switch layerL3
Quality of Service (QoS) supportY
ARP inspectionY
Configuring Location Settings (CLI)Y
Basic switching RJ-45 Ethernet ports quantity48
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity48
SFP+ module slots quantity4
Console portRJ-45
Power connectorAC-in jack
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z
10G supportY
Port mirroringY
Link aggregationY
Broadcast storm controlY
Rate limitingY
Spanning tree protocolY
Network virtualization technologiesQ-in-Q tunneling
QinQ implementationSelective QinQ
VLAN supportY
Virtual LAN featuresMAC address-based VLAN, Port-based VLAN, Protocol-based VLAN, Tagged VLAN, VLAN Identifier ( VLAN ID), Voice VLAN
Number of VLANs4096
MAC address table16000 entries
Forwarding rate130.944 Mpps
Store-and-forwardY
Jumbo frames supportY
Jumbo frames12000
Packet buffer memory512 MB
DHCP featuresDHCP relay, DHCP server, DHCP snooping
Access Control List (ACL)Y
IGMP snoopingY
IGMP proxyY
Security algorithmsSNMPv3
SSH/SSL supportY
AuthenticationGuest VLAN, Web-based authentication
Password protectionY
DoS attack preventionY
Authentication typeRADIUS
Queue scheduling algorithmsPriority queuing (PQ), Weighted Round Robin (WRR)
Multicast supportY
Multicast Listener Discovery (MLD) snoopingv1/v2
GARP VLAN Registration Protocol (GVRP)Y
IPv4 & IPv6 featuresIPv6 Telnet
Rack mountingY
Product colourGrey
Housing materialMetal
Reset buttonY
LED indicatorsLink, PoE, Power
Country of originChina
CertificationCE
Internal memory32 MB
Firmware upgradeableY
TelnetY
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current6 A
Power consumption (max)473.7 W
Power over Ethernet (PoE)Y
Power over Ethernet (PoE) ports quantity48
Power over Ethernet (PoE) power per port30 W
Total Power over Ethernet (PoE) budget400 W
Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 90%
Width440 mm
Depth330 mm
Height44.5 mm
Weight4.52 kg
Cables includedAC
Quick start guideY
Package typeBox
Rack mount kitY
Rubber feetY
Package width596 mm
Package depth390 mm
Package height80 mm
Package weight6 kg
Sustainability certificatesRoHS
Harmonized System (HS) code85176990
