Digitus Gigabit Ethernet PCI Express Card, 2-port

Reference DN-10132

Condition: New

More info

Gigabit Ethernet PCI Express Card, 2-port 32-bit, low profile bracket, Intel chipset

Expand your PC with PCIe slot by 2 Gigabit Ethernet ports with 1000 Mbit/s each

Gigabit data transfer for each RJ45 port
Suitable for standard slots & small PC case with low-profile slot
Layer 2 functions: IEEE 802.3x Flow Control, IEEE 802.1q VLAN
Intel chipset 82575EB
RSS, auto MDI/MDIX, IPv4, IPv6
Jumbo Frames 9.5k, VMDq

The DIGITUS® PCI Express Dual Port Gigabit Network Card with integrated Intel chipset offers the option to make two Gigabit ports for a server or a workstation available via a single PCI slot. Each port is fully compatible in accordance with IEEE802.3/u/ab standards and offers a full Gigabit connection. In addition to supporting IPv4 and IPv6 protocols, the card also supports jumbo frames as well as layer 2 functions such as IEEE802.1q VLAN and IEEE802.3x flow control. Its versatile configuration options make the card perfect for using with virtual machines or to set up a router/firewall. The low-profile slot bracket included in delivery also offers the option of integrating the card into compact computer cases in which standard slot brackets cannot be used.

Data transmission speed: 1 Gbps per port
Connections: 2 x RJ45
Chipset: Intel 82575EB (JL82575EB)
PCIe slot: PCI Express X 1
PCI Express channels: 1
Additional low-profile slot, so that the card can be used in computers with little space
Supports PCI bus power management interfaces rev 1.1 specifications
Complies with IEEE802.3ab, IEEE802.3u and IEEE802.3 specifications
Half-Duplex @ 10/100 Mbps, Full-Duplex @ 10/100/1000 Mbps
Layer 2 functions: IEEE 802.3x Flow Control, IEEE 802.1q VLAN
Supports auto MDI/MDIX crossover at all speeds
Supports RSS (Receive Side Scaling)
Supports IPv4, IPv6 protocols
Supports jumbo frames up to 9.5K
Supports UDP/TCP and IP checksum offloading
Supports Virtual Machine Device Queues (VMDq)
Supports VMDq - next generation (8VMs)
Supports statistics for management and remote monitoring
Driver support for MVMware ESXi 6.5 /6.5U1 / 6.5U2 / 6.5U3 / 6.7/ 6.7U1/ 6.7U2/ 6.7U3
Operating temperature: 0 °C ~ 55 °C
Operating humidity: 10 - 90% (non condensing)
Storage temperature: -60 °C ~ 140 °C
Storage humidity: 10 - 80% (non condensing)

Package content:
Gigabit Ethernet PCI Express card, 2-port
Low-profile slot bracket
Drivers on CD
QIG
