20m Fibre Optic Hybrid Mini DisplayPort 1.4 Cable with Detachable DP Connectors

LIN38481

New

Connectors

  • Connector A: Mini DisplayPort Male
  • Connector B: Mini DisplayPort Male
  • Housing Material: Zinc Alloy
  • Connector Plating: Gold Plated
  • Pin Construction: Gold-plated Brass
  • Pin Plating: Gold Plated
  • Dimensions (approx.) WxDxH:
    • Mini DisplayPort Connector: 38x13.9x12mm (1.5x0.55x0.47in)
    • DisplayPort Connector: 43x20x12mm (1.69x0.79x0.47in)
  •

Cable Construction

  • Length: 20m (65.62ft)
  • Standard: DisplayPort 1.4
  • Colour: Black
  • Type: Round
  • Jack Diameter: 4.8mm (0.19in)
  • Jack Material: PVC
  • Conductor Material: Gold Plated Copper



Specifications

  • Supported Bandwidth: 32.4Gbit/s
  • Maximum Resolution:
    • 7680x4320@60Hz 4:2:0 10bit
    • 4096x2160@120Hz 4:4:4 10bit
  • Nominal Attenuation: -1dB~-2dB
  • Minimum Bend Radius: 48mm (1.89in)
  • Operating Temperature: 0°C - 50°C (32°F - 122°F)
  • Storage Temperature: -25°C - 85°C (-13°F - 185°F)



Miscellaneous

  • Packaging Type: Carton box
  • Warranty (Years): 2
  • Certificated: CE, FCC, RoHS, REACH & California Proposition 65



Purchasing Information

  • No.: 38481
  • EAN: 4002888384810



This product is also available in other lengths

  • 38480 - 10m (32.81ft)
  • 38481 - 20m (65.62ft)
  • 38482 - 30m (98.42ft)
  • 38483 - 40m (131.23ft)
  • 38484 - 50m (164.04ft)
  • 38485 - 70m (229.66ft)
  • 38486 - 100m (328.08ft)
