| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 8 |
| Networking standards | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| 10G support | N |
| Port mirroring | Y |
| Full duplex | Y |
| Half duplex | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Rate limiting | Y |
| Auto MDI/MDI-X | Y |
| Auto-negotiation | Y |
| MAC address auto-learning supported | Y |
| MAC address auto-aging supported | Y |
| VLAN support | Y |
| Virtual LAN features | Tagged VLAN |
| Number of VLANs | 32 |
| MAC address table | 4000 entries |
| Switching capacity | 16 Gbit/s |
| Number of queues | 4 |
| Jumbo frames support | Y |
| Jumbo frames | 9000 |
| Packet buffer memory | 1.5 MB |
| IGMP snooping | Y |
| Multicast support | Y |
| Rack mounting | N |
| Product colour | Black |
| LED indicators | Link, Power |
| Country of origin | China |
| Flash memory | 2 MB |
| Fanless | Y |
| Mean time between failures (MTBF) | 43800 h |
| Master (outer) cases per pallet (air) | 16 pc(s) |
| Pallet gross length | 80 cm |
| Pallet gross width | 120 cm |
| Pallet height (air) | 170.4 cm |
| Power source | DC |
| Power supply included | Y |
| DC input voltage | 12 V |
| Input current | 1 A |
| Power consumption (max) | 6 W |
| Surge protection | Y |
| Surge protection voltage | 8 kV |
| Power over Ethernet (PoE) | N |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
| Heat dissipation | 20.4 BTU/h |
| Width | 160 mm |
| Depth | 95 mm |
| Height | 29 mm |
| Weight | 350 g |
| Quick start guide | Y |
| AC adapter included | Y |
| Package type | Box |
| Package width | 264 mm |
| Package depth | 122 mm |
| Package height | 52 mm |
| Package weight | 500 g |
| Sustainability compliance | Y |
| Sustainability certificates | CE, RoHS |
| Master (outer) case net weight | 700 g |
| Master (outer) case width | 550 mm |
| Master (outer) case length | 330 mm |
| Master (outer) case height | 390 mm |
| Master (outer) case gross weight | 18.7 kg |
| Products per master (outer) case | 36 pc(s) |
