Delock MiniPCIe IO PCIe full size 1 x Gigabit LAN

DELOCK

95228

New

This miniPCIe adapter by Delock expands your system by one Gigabit LAN interface, which you can lead out via the slot bracket.

More details

Description:
This miniPCIe adapter by Delock expands your system by one Gigabit LAN interface, which you can lead out via the slot bracket.

Specification:
• Chipset: JMicron JMC250B
• Form factor: miniPCIe full size
• Interface: PCI Express revision 1.1
• Connector: 1 x Gigabit LAN
• Data transfer rate up to 10/100/1000 Mb/s
• Compatible with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
• Supports Wake On LAN (WOL) and remote wake-up
• Automatic MDI/MDI crossover correction
• Supports IEEE 802.1P layer 2 priority encoding
• Supports IEEE 8021Q VLAN insertion and removal
• Integrated switching regulator and 3.3 V power source
• Cable length with connector: ca. 30 cm
• Operating temperature: 0 °C ~ 65 °C

System requirements:
• Windows Vista/7/7-64/8/8-64/8.1/8.1-64
• Mainboard with a free miniPCIe slot with a PCIe interface
• PC with one free slot

Package content:
• MiniPCIe module
• Connecting cable
• Gigabit LAN slot bracket
• Driver CD
• User manual
