HDMI to VGA and Audio Converter

LIN38285

New

Specifications

  • AV Interface: HDMI to VGA & 3.5mm Stereo Audio
  • Interface Standard: HDMI 1.3, VGA
  • Supported Bandwidth: 180MHz
  • Maximum Input Resolution: 1920x1200
  • Maximum  Output Resolution: 1920x1200@60Hz
  • Chipset: Algoltek AG6200A
  • HDCP Support: -
  • Supported Audio: Pass-through
  • Separate Audio Ports: 3.5mm Stereo Audio socket
  • Special Features: USB Micro B socket for power



Connectors

  • Input: HDMI Type A Male
  • Output: VGA Female, 3.5mm Stereo Audio Female, USB Micro-B Female (Power)



Physical properties

  • Dimensions (approx.) WxDxH:
    • 45x43x14.5mm (1.77x1.69x0.57in)
    • 21x17.4x9.6mm (0.83x0.69x0.38in) / HDMI
  • Cable Length: 100mm (3.94in)
  • Housing Material: ABS
  • Jacket Material: PVC
  • Jacket Diameter: 4.8mm (0.19in)
  • Minimum Bend Radius: 4.8mm (0.19in)
  • Net Weight: 0.031kg (0.07lb)
  • Operating Temperature: 0°C - 70°C (32°F - 158°F)
  • Storage Temperature: -10°C - 80°C (14°F - 176°F)
  • Humidity: 5 - 95% RH (non-condensing)
  • Colour: Black



Miscellaneous

  • Packaging Type: Polybag
  • Packaging Dimensions: 160x160x20mm (6.3x6.3x0.79in)
  • Gross Weight: 0.041kg (0.09lb)
  • Warranty (Years): 2
  • Certificated: CE, FCC, RoHS & REACH



Package Contents

  • HDMI to VGA and Audio Converter



Purchasing Information

  • No.: 38285
  • EAN: 4002888382854
