Level One LevelOne Switch 24x GE GEP-2652 2xGSFP 19" 370W 24xPoE+

LEVEL ONE

GEP-2652

Jauns

The LevelOne GEP-2652, the latest web smart generation, is equipped with 24 PoE ports and 2 Gigabit SFP ports. It offers powerful Layer2 capabilities, enhanced PoE functionality and a total PoE budget of 370W. The switch also supports advanced IPv6 management, IPv6 security and IPv6 multicast control to accommodate the growth of IPv6 deployment. Moreover, at an exceptional price/performance ratio. The PoE-enabled GEP-2652 has IEEE 802.3af/at certification, eliminating the challenges associated with standardized devices. It is therefore ideal for companies that want to operate VoIP telephones, wireless access points or network cameras. The GEP-2652 supports up to 30W output power per PoE port, giving you power distribution flexibility for a wide range of PoE PD devices. Adjust your network infrastructure as your business grows and save operating costs with easier management.

Switch typeManaged
Switch layerL2
Quality of Service (QoS) supportY
ARP inspectionY
Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity24
SFP module slots quantity2
Console portRJ-45
Power connectorAC-in jack
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z
10G supportN
Port mirroringY
Link aggregationY
Broadcast storm controlY
Rate limitingY
Spanning tree protocolY
Network virtualization technologiesQ-in-Q tunneling
QinQ implementationSelective QinQ
VLAN supportY
Virtual LAN featuresMAC address-based VLAN, Port-based VLAN, Protocol-based VLAN, Tagged VLAN, VLAN Identifier ( VLAN ID), Voice VLAN
Number of VLANs4000
MAC address table8000 entries
Forwarding rate38.69 Mpps
Store-and-forwardY
Jumbo frames supportY
Jumbo frames9000
Packet buffer memory128 MB
DHCP featuresDHCP snooping
Access Control List (ACL)Y
IGMP snoopingY
IGMP proxyY
Security algorithmsSNMPv3
SSH/SSL supportY
AuthenticationGuest VLAN, Web-based authentication
Password protectionY
DoS attack preventionY
Authentication typeRADIUS
Queue scheduling algorithmsPriority queuing (PQ), Weighted Round Robin (WRR)
Multicast supportY
Multicast Listener Discovery (MLD) snoopingv1/v2
GARP VLAN Registration Protocol (GVRP)Y
IPv4 & IPv6 featuresIPv6 Telnet
Rack mountingY
Product colourGrey
Housing materialMetal
Reset buttonY
LED indicatorsLink, PoE, Power
Country of originChina
CertificationCE
Internal memory8 MB
Firmware upgradeableY
TelnetY
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current6.5 A
Power consumption (max)435 W
Power over Ethernet (PoE)Y
Power over Ethernet (PoE) ports quantity24
Power over Ethernet (PoE) power per port30 W
Total Power over Ethernet (PoE) budget370 W
Operating temperature (T-T)0 - 45 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 90%
Width440 mm
Depth208 mm
Height44 mm
Weight3.87 kg
Cables includedAC
Quick start guideY
Package typeBox
Rack mount kitY
Rubber feetY
Resource CDY
Package width555 mm
Package depth295 mm
Package height88 mm
Package weight4.2 kg
Sustainability certificatesRoHS
Harmonized System (HS) code85176990
