Level One LevelOne ind. Netzteil POW-4821 48VDC 75W DIN-Schiene PoE

Kods POW-4821

Condition: Jauns

Vairāk informācijas

The POW-4820 is a DIN-rail industrial power supply is ruggedized, universal input voltage range and full compliance with all important safety and EMC standards. It can be operated at full load across an ambient temperature range of -20 to 60 Celsius degree without need of additional cooling to guarantee quality for harsh industrial environment. Moreover, this power unit has been designed specifically for use with Infinity Industrial PoE Ethernet series, also it meets the requirements for both PoE and PoE Plus as well.

Total power	75 W
AC input voltage	90 - 264 V
Peak power	76.8 W
Power protection features	Over voltage, Overload, Short circuit
Mean time between failures (MTBF)	506600 h
Safety	UL508, TUV EN60950-1, EAC TP TC 004, BSMI CNS14336-1 approved;(meet EN60204-1)
Country of origin	China
Product colour	Mint colour, Silver
LED indicators	Y
Operating temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 95%
Width	125.2 mm
Depth	102 mm
Height	32 mm
Weight	510 g
Package width	125.2 mm
Package depth	102 mm
Package height	32 mm
Package weight	510 g
Harmonized System (HS) code	84733020
Maximum current	1.6 A
Power over Ethernet (PoE)	Y
Technical features	48V DC Out
