INTELLINET 24-Port Gigabit Switch Desktop & 19"Rackmount Met

INTELLINET

561273

Jauns

Boost your network speed. _x000D_ _x000D_ The Intellinet Network Solutions 24-Port Gigabit Ethernet Switch (561273) offers an array of features while providing superior network throughput. It is very easy to set up and requires no configuration whatsoever. Thanks to its desktop and 19"; rackmount design, superior performance and value, the Intellinet Network Solutions 24-Port Gigabit Ethernet Switch is the perfect choice for expanding your small office home or home network. _x000D_ _x000D_ Extreme Throughput _x000D_ With a backplane speed of 48 Gbps, plenty of performance is available for your computers, servers and other networking devices. _x000D_ _x000D_ Auto Features _x000D_ This Gigabit LAN switch includes many automatic features that make it easy to use. No configuration is required, so installation is Plug and Play and hassle-free. Auto-MDI/MDI-X crossover on all ports eliminates the need for any crossover cables. Each of the 24 ports automatically senses the link speed of the connected network device and adjusts to 10, 100 or 1000 Mbps for compatibility and maximum performance. _x000D_ _x000D_ Reliable Operation _x000D_ The Intellinet Network Solutions 24-Port Gigabit Ethernet Switch supports flow control when operating in half-duplex mode and IEEE 802.3ab in full duplex mode to ensure that data transfer and network connectivity run smoothly and uninterrupted. In conjunction with the broadcast storm control and the store-and-forward switching method, full- and half-duplex modes further ensure that your connections remain active even under extremely busy conditions. _x000D_ _x000D_ Green Ethernet Technology _x000D_ More often than not, a network switch does not utilize all its ports at all times. Normally, when a computer, notebook, network printer or other network-connected device is powered down, the switch continues to consume the same amount of power as if it were active. Now, thanks to the new, energy efficient IEEE 802.3az technology, the Intellinet Network Solutions 24-Port Gigabit Switch detects link status to all connected devices and reduces the power usage of ports not in use. In addition, the Intellinet Network Solutions switch can adjust the level of power output based on the length of the network cable connected to a particular port. This feature allows for the enjoyment of maximum network performance, and when things slow down, it automatically scales back power usage to conserve energy and save money.

Control and Provisioning of Wireless Access Points (CAPWAP)Y
Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Power connectorAC-in jack
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x
10G supportN
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
Cable types supportedCat3, Cat4, Cat5, Cat5e
Full duplexY
Flow control supportY
Auto MDI/MDI-XY
Auto-sensingY
Auto-negotiationY
MAC address auto-learning supportedY
MAC address auto-aging supportedY
MAC address table16384 entries
Switching capacity48 Gbit/s
Store-and-forwardY
Jumbo frames supportY
Jumbo frames9000
Packet forwarding rate (1 Gbps)1488000 pps
Packet forwarding rate (100 Mbps)148800 pps
Packet forwarding rate (10 Mbps)14880 pps
Packet buffer memory0.512 MB
Rack mountingY
Product colourBlack
Housing materialMetal
LED indicatorsActivity, Link, Power
CertificationFCC A, CE
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)16 W
Power over Ethernet (PoE)N
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 70 °C
Operating relative humidity (H-H)10 - 90%
Width280 mm
Depth180 mm
Height44 mm
Weight2.6 kg
Cables includedAC
User guideY
Rack mount kitY
Harmonized System (HS) code85176990
