Zyxel Switch 12x GE RGS200-12P Managed PoE Switch

ZYXEL

RGS200-12P-ZZ0101F

New

12-port GbE Managed PoE Switch

Along with the complete commercial product portfolio that offers customers with total network solutions, Zyxel introduces the new RGS Series of PoE switches with ruggedized design concepts to meet stringent outdoor or harsh network deployment scenarios. The special mechanism enables RGS200-12P to operate in outdoor, factory or other harsh environments for surveillance. In addition, it is also easy to manage RGS200-12P through a user-friendly Webbased GUI.

Benefits

Rugged and reliable design for harsh environments
Equipped with fanless and IP30 standard metal mechanism, the Zyxel RGS200-12P is able to deliver great thermal control and tolerate the dustiest deployments with ease, whether installed on a DIN rail or wall mounted for the most efficient use of cabinet space. Designed to handle temperatures ranging from -40°C to 75°C, the RGS200-12P can be placed in a variety of challenging environments and be adapted to broad range of field applications. When switching is applied normally in outdoor settings, ESD (electrostatic discharge), DC and Ethernet surge protection prevent the loss of business revenue and productivity due to damage or fatigue caused by power disturbances.

Quick failover for stable connectivity
When deployed in harsher conditions, such as factory or outdoor settings, the Zyxel RGS200-12P creates fault-tolerant networks with redundant ring technology and rapid self-recovery capability to prevent interruptions. In the event of downtime caused by a network error, the rapid failover will restore normal operation in less than 20 ms. The switch’s dual DC power inputs and reverse power protection feature ensure continuous uptime and reliable operation.

Trouble-free installation and easy extendibility
This rugged L2 Managed PoE switch comes with eight (8) 10/100/1000 Base-T copper PoE ports and four (4) 100/1000-Base-X SFP fiber interfaces. The switch also supports the 802.3at PoE plus standard, with each PoE port providing up to 30 W of power to efficiently accommodate the most power-hungry devices. The fiber uplink can extend the network to long-distance nodes up to 40 km (43,744 yards) away for added flexibility.

Switch typeManaged
Switch layerL2
Quality of Service (QoS) support
Web-based management
ARP inspection
System event log
MIB supportRFC 2233 IF MIB, RFC1213 MIB II, RFC 1757 RMON 1/2/3/9, RFC1215, RFC1493, RFC 2674, LLDP-EXT-MED MIB
Basic switching RJ-45 Ethernet ports quantity8
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
SFP module slots quantity4
Fiber optic connectorSFP
Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroring
Full duplex
Flow control support
Link aggregation
Broadcast storm control
Rate limiting
Auto-negotiation
VLAN support
Virtual LAN featuresTagged VLAN
Number of VLANs1024
Fiber ethernet cabling technology1000BASE-X
Transmission distance (max)40 km
MAC address table8000 entries
Switching capacity24 Gbit/s
Throughput17.86 Mpps
Store-and-forward
Number of queues8
Jumbo frames support
Jumbo frames9000
Packet buffer memory0.5 MB
Access Control List (ACL)
IGMP snooping
Security algorithms802.1x RADIUS, HTTPS, SNMP, SSH-2
MAC address filtering
SSH/SSL support
AuthenticationGuest VLAN, MAC-based authentication, Port-based authentication
Multicast support
Rack mounting
Product colourBlack
Housing materialMetal
International Protection (IP) codeIP30
Wall mountable
DIN rail mounting
Firmware upgradeable
Buffer size512 KB
Plug and Play
Mean time between failures (MTBF)568430 h
DC input voltage12 - 58 V
Input voltage12 - 58 V
Power consumption (max)255 W
Power over Ethernet (PoE)
Power over Ethernet plus (PoE+) ports quantity8
Total Power over Ethernet (PoE) budget240 W
Operating temperature (T-T)-40 - 75 °C
Storage temperature (T-T)-40 - 85 °C
Operating relative humidity (H-H)5 - 95%
Storage relative humidity (H-H)5 - 90%
Heat dissipation86955 BTU/h
Width77 mm
Depth127.3 mm
Height154 mm
Weight1.45 kg
Wall mounting kit
Rack mount kit
Package width133 mm
Package depth192 mm
Package height238 mm
Package weight1.9 kg
Harmonized System (HS) code85176990

Industrial networks
